GESYNTECH 12S8P rechargeable battery
12S8P Rechargeable Battery for FPV
The lithium-ion battery «GESYNTECH 12S8P» provides the opportunity to use modern power supply technology anywhere at an affordable price. It can be used to support reliable power supply of various types of equipment as part of autonomous power supply systems.
The «GESYNTECH 12S8P» batteries are assembled from new Li-Ion cells according to the 6S8P scheme.
The product is non-toxic and does not pollute the environment.
10045 ₴
-
Purpose power supply systems Dimensions W*H*D, mm 130 x 75 x 350 Weight, kg 7.0 Electrical diagram (S series and P parallel number of elements) 6S8P+6S8P Nominal capacity, W*h / A*h 1382.4 / 32 Nominal output voltage, V 21.6+21.6 =43.2 Maximum/minimum total allowable voltage, V 25.2+25.2=50.4/18+18=36 Recommended charge/discharge current, A 16/140 Maximum charge/discharge current (A) 48/225 Type of installed BMS - Operating temperature (°C) (+5°C - +45°C) Storage temperature (°C) (-10°C - +45°C) Relative humidity of operation and storage 50 ± 15% Expected service life 7 years + Power connector’ QS8P + QS8P Element type TENPOWER 40TG Element capacity, A*h 4.0 Balancing wires 22AWG Balanced connector XH2.54 7pin + XH2.54 7pin Power wires 6AWG Length of power wires, m 0.1 -
