GESYNTECH 4S5P rechargeable battery
4S5P Rechargeable Battery for FPV
The lithium-ion battery «GESYNTECH 4S5P» provides the opportunity to use modern energy supply technology anywhere at an affordable price. It can be used to support reliable power supply of various types of equipment as part of autonomous energy supply systems.
The «GESYNTECH 4S5P» batteries are assembled from new Li-Ion cells according to the 4S5P scheme.
The product is non-toxic and does not pollute the environment.
3480 ₴
-
Purpose power supply systems Dimensions W*H*D, mm 106x75x85 Weight, kg 1.42 Electrical diagram (S series and P parallel number of cells) 4S5P Nominal capacity, W*h / A*h 288 / 20 Nominal output voltage, V 14.4 Maximum/minimum total allowable voltage, V 16.8/12 Recommended charge/discharge current, A 10/100 Maximum charge/discharge current (A) 0/150 Type of installed BMS - Operating temperature (°C) (+5°C - +45°C) Storage temperature (°C) (-10°C - +45°C) Relative humidity of operation and storage 50 ± 15%. Expected service life 7 years + Power connector’ XT90 Cell type TENPOWER 40TG Cell capacity, A*h 4.0 Balancing wires 22AWG Balancing connector XH2.54 7pin Power wires 10AWG Length of power wires, m 0.1 -
