GESYNTECH 6S3P rechargeable battery
6S3P Rechargeable Battery for FPV
The lithium-ion battery «GESYNTECH 6S3P» provides the opportunity to use modern energy supply technology anywhere at an affordable price. It can be used to support reliable power supply of various types of equipment as part of autonomous energy supply systems.
The batteries «GESYNTECH 6S3P» are assembled from new Li-Ion cells according to the 6S3P scheme.
The product is non-toxic and does not pollute the environment.
3190 ₴
-
Purpose power supply systems Dimensions W*H*D, mm 65 x 75 x 130 Weight, kg 1.32 Electrical diagram (S series and P parallel number of cells) 6S3P Nominal capacity, W*h / A*h 259.2/12 Nominal output voltage, V 21.6 Maximum/minimum total allowable voltage, V 25.2/18 Recommended charge/discharge current, A 6/50 Maximum charge/discharge current (A) 20/90 Type of installed BMS - Operating temperature (°C) (+5°C - +45°C) Storage temperature (°C) (-10°C - +45°C) Relative humidity of operation and storage 50 ± 15%. Expected service life 7 years + Power connector’ XT60 Cell type TENPOWER 40TG Cell capacity, A*h 4.0 Balancing wires 22AWG Balancing connector XH2.54 7pin Power wires 10AWG Length of power wires, m 0.1 -
