GESYNTECH 8S5P rechargeable battery
8S5P Rechargeable Battery for FPV
The lithium-ion battery «GESYNTECH 8S5P» provides the opportunity to use modern energy supply technology anywhere at an affordable price. It can be used to support reliable power supply of various types of equipment as part of autonomous energy supply systems.
The «GESYNTECH 8S5P» batteries are assembled from new Li-Ion cells according to the 8S5P scheme.
The product is non-toxic and does not pollute the environment.
7300 ₴
-
Purpose power supply systems Dimensions W*H*D, mm 105x75x175 Weight, kg 3.1 Electrical diagram (S series and P parallel number of cells) 8S5P Nominal capacity, W*h / A*h 576 / 20 Nominal output voltage, V 28.8 Maximum/minimum total allowable voltage, V 33.6/24 Recommended charge/discharge current, A 10/100 Maximum charge/discharge current (A) 30/150 Type of installed BMS - Operating temperature (°C) (+5°C - +45°C) Storage temperature (°C) (-10°C - +45°C) Relative humidity operation and storage 50 ± 15%. Expected service life 7 years + Power connector XT90 Cell type TENPOWER 40TG Cell capacity, A*h 4.0 Balancing wires 22AWG Balancing connector XH2.54 9pin Power wires 10AWG Length of power wires, m 0.1 -
